MCB Shunt Release

CDADA is a reliable factory since 1983, our MCB Shunt Release is designed to provide a dependable solution for remotely controlling your DAB7-63 circuit breakers. Whether you need an emergency stop function or integration into an automated system, our shunt release offers the performance and flexibility you require.

Product Highlights

★ Purpose: Remote disconnection of MCBs for emergency shutdowns or system automation.

★ Voltage Range: Compatible with AC 50Hz (24V to 400V) and DC (24V to 220V) supplies.

★ Reliability: Operates reliably within 70% to 110% of rated voltage.

★ Compatibility: Designed specifically for DAB7-63 MCBs—no adapters required.

★ Ease of Installation: Quick and straightforward installation process.

★ Our Recommendation: For optimal performance, ensure the applied control voltage falls within the specified range of 70% to 110% Us.

Technical Specifications

Installation & Usage Guide

To get the most out of your CDADA MCB Shunt Release, follow these steps:

★ Verify Compatibility: Ensure the control voltage matches the specifications of the shunt release.

★ Mounting: Attach the shunt release directly onto the left side of the DAB7-63 MCB.

★ Wiring: Connect your control signal to the designated terminals on the shunt release.

★ Use shielded cables for long distances to avoid interference.

★ Testing: Apply the control voltage to confirm the breaker opens as expected.

★ Maintenance Tip: Regularly inspect the wiring connections for signs of wear or damage. Keep the area around the shunt release clean and free from dust to ensure reliable operation.

Wiring Diagram Overview

The wiring diagram for the CDADA MCB Shunt Release is straightforward:

★ Control Signal: Connect your external control device to the terminals provided.

★ Breaker: The shunt release is mechanically coupled to the breaker’s actuation mechanism, ensuring immediate disconnection when triggered.

★ Installation Note: Always double-check your wiring before applying power to avoid any potential hazards.

Frequently Asked Questions

Q1: What is an MCB shunt release used for?

A1: An MCB shunt release allows for remote disconnection of the circuit breaker, which can be critical for emergency stops or integrating into automated systems.

Q2: Can I use this shunt release with any MCB?

A2: No, the CDADA MCB Shunt Release is specifically designed for use with the DAB7-63 series. It will not fit other brands without modification.

Q3: Is the shunt release suitable for both AC and DC applications?

A3: Yes, our shunt release supports both AC (24V to 400V) and DC (24V to 220V) applications, providing versatility across various environments.

Q4: Why choose CDADA shunt release over others?

A4: At CDADA, we prioritize:

● Quality Assurance: Each unit undergoes rigorous testing.

● Ease of Installation: Direct compatibility with DAB7-63 MCBs—no additional adapters needed.

● Customer Support: Direct assistance from our experienced team.

● Cost-Effectiveness: Competitive pricing without compromising on quality.

Final Note from CDADA

Choosing the right shunt release can significantly enhance the safety and functionality of your electrical systems. With CDADA, you’re not just getting a component—you’re gaining a partner committed to excellence in every detail. Let us help you achieve peace of mind with our dependable and easy-to-use solutions.
