MCCB Auxiliary Contact

CDADA is a reliable supplier and we understand that reliable auxiliary contacts are crucial for ensuring the safety and efficiency of your electrical systems. Our CDADA MCCB Auxiliary Contacts provide precise indication of the open and close states of your MCCBs (Molded Case Circuit Breakers), making them indispensable for both industrial and commercial applications. Whether you're designing a new system or upgrading an existing one, our auxiliary contacts offer the flexibility and dependability you need.

Product Highlights

Purpose: Monitor and control the state of MCCBs.

Configurations: Available in 1NO/1NC, 2NO/2NC, and 4NO/4NC options.

Compatibility: Designed to work seamlessly with CDADA MCCBs, but also compatible with many other brands.

Ease of Installation: Pre-wired for quick and easy setup.

Durability: Built to withstand harsh environments and frequent use.

Our Recommendation: For most applications, the 2NO/2NC configuration offers a balanced approach between functionality and cost-effectiveness.

Technical Specifications

Installation & Usage Guide

To ensure proper operation and longevity of your CDADA MCCB Auxiliary Contacts, follow these guidelines:

★ Verify Compatibility: Ensure the contact configuration matches your application requirements and MCCB model.

★ Installation: Connect according to the wiring diagram provided.

● For Inm = 63A-225A, use 1 set of auxiliary contacts (but 2 sets supplied).

● For Inm = 250A-1600A, use 2 sets of auxiliary contacts (but 4 sets supplied).

★ Testing: Before full deployment, test the auxiliary contacts under controlled conditions to confirm proper function.

Maintenance Tip: Regularly check connections for signs of wear or corrosion. Keep the area clean to prevent dust accumulation which could affect performance.

Wiring Diagram Overview

The wiring diagram varies slightly depending on the MCCB current rating:

★ For Inm = 63A-225A:

★ Closed Position: Use 1 set of auxiliary contacts (2 sets provided).

★ Open Position: Similarly, use 1 set of auxiliary contacts (2 sets provided).

★ For Inm = 250A-1600A:

★ Closed Position: Use 2 sets of auxiliary contacts (4 sets provided).

★ Open Position: Likewise, use 2 sets of auxiliary contacts (4 sets provided).

★ Installation Note: Always refer to the specific wiring diagrams included with your product for accurate connections.

FAQ

Q1: What is an MCCB auxiliary contact used for?

A1: An auxiliary contact is used to monitor and indicate the open/close state of an MCCB, enabling remote monitoring and control of the circuit breaker.

Q2: Can I install this auxiliary contact on any MCCB?

A2: While designed primarily for compatibility with CDADA MCCBs, they may fit other brands as well. Verify specifications and consult with our technical team if unsure.

Q3: How do I choose between NO and NC contacts?

A3: Normally Open (NO) contacts close when the MCCB closes, while Normally Closed (NC) contacts open. Choose based on your system’s needs for signaling and control.

Q4: Why choose CDADA MCCB Auxiliary Contacts?

A4: At CDADA, we focus on:

● Quality Assurance: Each unit undergoes rigorous testing.

● Ease of Integration: Simple installation and compatibility with various MCCBs.

● Customer Support: Direct access to our experienced technical team.

● Cost-Effectiveness: High-quality components at competitive prices.

Final Note from CDADA

Choosing the right auxiliary contact can significantly enhance the reliability and functionality of your electrical systems. With CDADA, you’re investing in quality products backed by expert support. Let us help you achieve superior system performance and safety with our dependable solutions.
